Premier Mounts Extra Large Back-to-Back TV Ceiling Mount ECM-3763D

Mfg Part # ECM-S / ECM-S2
Availability: In Stock
Delivered Free in 3-9 Days. Expedited Shipping Available.
MSRP $863.00
Price: $620.00 You Save $243.00 (28 %)

The Elliptical Ceiling Mount Series is the latest mounting innovation from Premier Mounts.  Designed from the ground up as universal ceiling mounts, the Elliptical Series do not require any additional adapters or accessories to accommodate displays from 37"-80+".   It features multiple cable management ports for improved cable routing as well as an aesthetic design that is best-in-class.  Pop-on covers hide all mounting hardware and AC receptacle mounting points makes wiring your displays a breeze. It features:

  • Perfect for digital signage applications.
  • Suspends two 37"-63" displays back to back from the ceiling
  • Adapts to 2" NPT. (NPT pipe not included)
  • 15° continuous tilt.
  • Fits up to 875  x 505 mm (W x H) mounting points.
  • Integrated cable management keeps your installation clean and uncluttered.
  • Mounts display right out of the box.  No adapters needed.
  • Includes AC receptacle mounting points for optional AC power outlets with standard junction box.
  • No exposed holes, mounting screws or hardware.
  • Adapters for signal converters, file servers, and A/V equipment mount directly to frame.
  • Works with the Mac Mini Adapter and the Mini PC adapter (sold separately, See "Related Products" below).
  • Backed by Premier Mounts' industry-leading Lifetime Warranty for true peace of mind.

Recommended for:

  • Dual 37-80+" flat screens with mounting patterns between VESA 200x200mm and 875x505mm (WxH) and 350 lbs. Please use Premier Mounts' Mount Finder for help selecting the appropriate mount or call our Sales Team.

*Please Note: For complete installation, this mount requires ceiling attachment hardware such as a ceiling plate and 2" drop-pipe (sold separately).

Weight:  Maximum Weight Capacity:
  65 lbs    350 lbs.

Click Here for Assembly Instructions!

Click on the last image above for technical specifications.
