Chief SMART LIFT Automated Projector Mount Lift (8 inch) SL151

Chief's SMART-LIFT Automated Projector Lift features:

• Must order SLB interface bracket separately
• Precise positioning including vertical projector cradle adjustment and fore/aft projector positioning
• Quick connect/disconnect for convenient lamp and filter access on most projectors
• Maintains registration even when disconnected
• Independent roll, pitch and yaw
• Low profile, requires minimal clearance above the ceiling
• Easy installation, the drop-in design fits into a 2' x 2' suspended ceiling
• Multiple installation options: three 0.38" (10 mm) threaded rods, 1.5" NPT threaded extension column with SMA602 accessory (not included), or side mount with built-in joist tabs
• UL Listed
• TAA compliant meets the needs of U.S. Government projects
• Roll: 2°, Pitch: 20° & Yaw: 5°
• Ceiling Closure: 20.2" x 20.3" ( 514 x 515 mm)
• Ceiling Opening: 23.5" x 23.5" x 11.2" (597 x 597 x 284 mm)
• Max Equip Size (H X W X D): 8.4" x 18.3" x 18.3" (213 x 464 x 464 mm)
• Power Requirements: 120 VAC, 60 Hz, 12 A
• Weight Capacity: 35 lbs (15.9 kg)
• FCC Approved, UL Listed

*For proper installation, this lift requires one SLB adapter plate. (Sold separately).

**Please Note: Electric lifts are considered Custom Orders and are not returnable.
